Self Developed IGBT Platform Evaluates Module Design Performance

Vector Frequency Inverter Product Description

The HV300 Series inverter is a cutting-edge, multi-function universal vector frequency inverter, also known as a variable frequency drive (VFD) or AC drive. This recently developed inverter incorporates advanced open-loop and closed-loop vector control technology, allowing precise control of asynchronous motors.

Designed with a focus on software functionality, performance enhancement, and reliability, the HV300 inverter offers a more compact size without compromising expandability. It provides users with a wider range of communication capabilities, enabling seamless integration into various industrial systems.

With its user-friendly interface and intuitive controls, the HV300 inverter ensures simpler operation and configuration. Its comprehensive features and parameters can be easily accessed and adjusted to meet specific application requirements.

The HV300 Series inverter offers advanced functionality, enhanced performance, and increased reliability. It is a versatile solution for various industrial applications, providing precise control, efficient operation, and simplified integration into existing systems.

Variable Frequency Inverter VFD Product Technical Specification

Variable Frequency Inverter VFD Product Typical Application

Oilfield Pumping Unit:

• Location: Oilfield
• Power: 22kW
• Efficiency: Achieve significant power savings of over 30% while protecting the grid and equipment from overcurrent issues.
• Key Advantages: Versatile voltage range for seamless adaptation to demanding grid conditions; Smooth speed control with low starting current, ensuring minimal impact on the grid; Equipped with built-in EMC filter and standard-configured DC reactor, reducing radiation.

Steel Plant Roller:

• Location: Tianjin steel plant
• Power: 22kW, 30kW, 37kW, 45kW
• Performance: Ensures exceptional operational stability with a fault rate below 1%.
• Key Advantages: Designed to handle reciprocating acceleration and deceleration, providing reliable performance; Capable of supporting long-term continuous operation; Built to withstand high temperatures and meet stringent protection requirements in steel workshops; Facilitates integration into Profibus DP network.

Steel Plant Cold Saw:

• Location: Tangshan steel plant
• Power: 450kW
• Performance: Enables high overload operation, maintaining stable speed control to meet process demands.
• Key Advantages: Exceptional overload capacity for heavy-duty operations; Quick response and precise speed control, even at high speeds; Engineered to withstand high temperatures and fulfill rigorous protection requirements in steel workshops; Supports seamless integration into Profibus DP network.

1. FAQ for South Korea

1. Q: Is the VFD suitable for high-tech manufacturing?
   A: Yes, with precise control and communication capabilities.

2. Q: How does it support Korea’s green energy policies?
   A: High efficiency and low harmonics align with national standards.

3. Q: Can it integrate with Korean PLC systems?
   A: Yes, Profibus and other protocols are supported.

4. Q: How does it handle seasonal temperature variations?
   A: Operating range from -40°C to +70°C ensures year-round reliability.

5. Q: Is it used in shipbuilding or marine applications?
   A: Yes, with optional corrosion protection.

6. Q: What is the harmonic performance?
   A: Meets IEEE 519 standards with DC reactor.

7. Q: Can I customize the control logic for automation?
   A: Yes, the built-in PLC allows full customization.

8. Q: How reliable is the short-circuit protection?
   A: It uses advanced IGBT technology for instant response.

9. Q: Are Korean language interfaces available?
   A: Yes, key parameters and alarms can be displayed in Korean.

10. Q: What is the lead time for Busan?
    A: We deliver within 3–5 days.
